PT100 daughterboard for Duet Wifi

PT100 daughterboard for Duet Wifi

This is a daughterboard specifically designed for the Duet range of controller boards that supports one or two PT100 temperature sensors in either two or four wire configuration. There are jumpers on the latest version of the board for easily switching between two and four wire mode.

The PT100 Daughter Board is compatible with all Duet 2 and 3 mainboards, along with the Expansion 3HC.

The Duet 3 and Duet 2 mainboards support up to two daughterboards, with a further daughterboards on Duet 3 3HC expansion boards or the on a Duex5 expansion board for Duet 2. With 4 daughter boards a total of 8 PT100 sensors are supported. PT100 and Thermocouple daughterboards can be mixed and matched.
