Duet 3 Expansion Board 3HC V1.02a

Name: Duet 3 Expansion Board 3HC V1.02a
SKU: Duet_3_EB_3HC_v1.02a
Price: 130.0 GBP
Availability: InStock

Store / Duet3D / Add Ons

£130.00

or four payments of £32.50 each with View details

In stock

Product Details

Duet 3 Expansion Board 3HC V1.02a

The Duet 3 Expansion board is a CAN-FD connected, high current, full featured expansion board for the Duet 3 mainboards. Pair one of these expansion boards with a Duet 3 Mainboard 6HC, Duet 3 Mainboard 6XD or a Duet 3 Mini 5+ to control 3 high current stepper drivers, 3 high current loads, 6 fans and 6 IO channels. Further 3HC expansion boards, tool boards and 1XD expansion boards can be added to the CAN-FD bus if necessary to complete your machine design.

FEATURES


Processor	Powerful 32bit Atmel ARM Cortex-M4F microcontroller running at up to 120MHz
Connectivity	CAN-FD BUS for connection to Duet 3 Mainboards (compatible with the Duet 3 Mainboard 6HC, Duet 3 Mainboard 6XD and the Duet 3 Mini 5+)
Stepper Drivers	3x TMC2160/5160 high-current drivers with the latest Trinamic features. Maximum motor current 6.3A peak per phase (4.45A RMS)
High current outputs	3x5A PWM outputs for extruders and similar
Medium current outputs	6 PWM controllable outputs for fans or similar. 3 of these support 4 wire fans including tacho reading
IO	6I/O connectors with 3.3V output signal level and 30V-tolerant inputs.
Temperature measurement	3 thermistor/PT1000 inputs. Support for two temperature daughterboards for up to 4 PT100 or thermocouple sensors.
Supply Voltage	12-48V v1.02 and later; 12-32V v1.01 and earlier
